VL-11 Metering Valves

The series VL-11 metering devices are for single-line, high-pressure lubrication system s. viscosity up to NLGI 2. Output is externally adjustable. An indicator pin permits visu al check of metering device operation. Individual metering devices can be removed eas ily for inspection or replacement.

Get a Quote Catalog Download

Technical Information of VL-11 Metering Valves

Technical characteristics
Outlets	1
Metering quantity	0.82 - 8.2 ml（adjustable）
Lubricant	Grease NLGI 0, 1, 2
Operating temperature	-40 ~93 °C
Operating pressure	70 to 240 bar
Material	stainless steel、Carbon steel
Connection main line	1/2 NPT (F)
Connection outlet	1/4 NPT (F)

Technical Drawing of VL-11 Metering Valves

Part number	Connection outlet
VL1100	1/4 NPT (F)

Characteristics of VL-11 Metering Valves

May be combined in a circuit of metering devices VL-1、VL-1X、VL-1XL、VL- 11、VL-32
Output is externally adjustable
Each indicator pin permits visual check of injector operation
Individual metering devices can be removed easily for inspection or replacement

Cisolube offers custom grease distributor with wide selections, Contact now.

Applications of VL-11 Metering Valves

Construction machinery
Mining and mineral processing
Steel industry
